ROLAIR 5520MK103A 120V Wheeled Electric Air Compressor
Model 5520MK103A is our entry-level 20 gallon wheelbarrow-style air compressor. The larger tank assembly allows the 5520MK103A to sustain 7.3 CFM @ 90 PSI longer than the traditional 9 gallon twin tank design. The low-RPM pump and motor combine for quiet operation and minimal amp draw.
| HORSE POWER | 1.5 HP |
| CFM DISPLACED | 10.1 CFM |
| CFM DELIVERED | 7.3 CFM @ 90 PSI |
| PUMP/MOTOR RPM | 1755 RPM |
| OVERLOAD PROTECTION | Yes (Manual Reset Standard) |
| LUBRICATION TYPE | Splash Lubrication |
| PUMP OIL CAPACITY | 17 oz. |
| REED VALVE SYSTEM | Yes (Standard) |
| NUMBER OF CYLINDERS | 2 |
| TANK CAPACITY | 20 Gallons |
| L X W X H | 42"x22"x34" |
| DECIBEL RATING | Unavailable |
| SHIPPING WEIGHT | 200 lb. |
Original: $1,397.00
-65%$1,397.00
$488.95ROLAIR 5520MK103A 120V Wheeled Electric Air Compressor
Model 5520MK103A is our entry-level 20 gallon wheelbarrow-style air compressor. The larger tank assembly allows the 5520MK103A to sustain 7.3 CFM @ 90 PSI longer than the traditional 9 gallon twin tank design. The low-RPM pump and motor combine for quiet operation and minimal amp draw.
| HORSE POWER | 1.5 HP |
| CFM DISPLACED | 10.1 CFM |
| CFM DELIVERED | 7.3 CFM @ 90 PSI |
| PUMP/MOTOR RPM | 1755 RPM |
| OVERLOAD PROTECTION | Yes (Manual Reset Standard) |
| LUBRICATION TYPE | Splash Lubrication |
| PUMP OIL CAPACITY | 17 oz. |
| REED VALVE SYSTEM | Yes (Standard) |
| NUMBER OF CYLINDERS | 2 |
| TANK CAPACITY | 20 Gallons |
| L X W X H | 42"x22"x34" |
| DECIBEL RATING | Unavailable |
| SHIPPING WEIGHT | 200 lb. |
